Industrial Gigabit Ethernet Fiber Media Converters 10/100/1000M, DIN Rail Mount

121.41 € – 121.43 € without VAT

Industrial Gigabit Ethernet Fiber Media Converters 10/100/1000M, DIN Rail Mount

Industrial Gigabit Ethernet Fiber Media Converter is designed for reliable data transmission in demanding industrial and outdoor environments. The device converts a 10/100/1000 Mbps Ethernet signal into an optical connection, enabling stable long-distance communication while protecting the network against electromagnetic interference and electrical surges. Depending on the model, the converters are available with 1, 2 or 4 RJ45 ports, as well as Multi-Mode, Single-Mode or Bi-Directional (BiDi) fiber optic interfaces.
The rugged IP40 aluminum enclosure, wide operating temperature range, and surge protection make these converters suitable for use in manufacturing facilities, power and utility installations, transportation infrastructure, outdoor communication cabinets, and weatherproof enclosures. The devices can be mounted on a standard DIN rail or directly on a wall, allowing easy integration into electrical, automation, and telecommunications cabinets.
These fiber media converters are ideal for IP surveillance systems, industrial automation, PLC controllers, wireless communication equipment, access control systems, network switches, and other Gigabit Ethernet applications.
Key Features
• Gigabit Ethernet (10/100/1000 Mbps)
• Models with 1, 2 or 4 RJ45 ports
• Multi-Mode, Single-Mode or Bi-Directional (BiDi) fiber interfaces
• Transmission distance up to 20 km (optional models available up to 80 km)
• Auto MDI/MDI-X and automatic speed negotiation
• Supports Jumbo Frames up to 9000 bytes
• Rugged IP40 aluminum enclosure
• DIN rail or wall mounting
• Wide-range power input: 12–52 V DC (power supply included)
• Operating temperature: -40 °C to +80 °C
• ESD, EFT and surge protection
• Shock and vibration resistant
• Low power consumption (<3 W) Technical Specifications Ethernet ports: 1 / 2 / 4 × RJ45 10/100/1000Base-T (depending on model) Fiber interfaces: • SC Multi-Mode • SC Single-Mode • SC Bi-Directional (BiDi) • SFP slot (selected models) Network standards: IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x Switching capacity: 14 Gbps Packet forwarding rate: 10.5 Mpps MAC address table: 2K Jumbo Frame: up to 9000 bytes Mounting: DIN rail or wall mounting Enclosure: IP40 aluminum housing Power supply: 12–52 V DC (redundant) Power consumption: <3 W Operating temperature: -40 °C to +80 °C Protection: ESD, EFT, Surge Dimensions: 118 × 85.7 × 33.5 mm Weight: 0.36 kg Typical Applications • CCTV surveillance systems • Industrial automation • PLC and SCADA systems • Manufacturing facilities • Power and utility installations • Transportation infrastructure • Outdoor communication cabinets • Wi-Fi access points • Telecommunications networks • Industrial Ethernet networks
